Claw coupling for compressed air DIN 3238
We supply claw coupling for compressed air DIN 3238 with high quality and good price.We are a manufacture for claw coupling for compressed air DIN 3238 in Ningbo China for many years.
Model:for hose ID 19 mm (3/4")
Send Inquiry
Product Description
We supply claw coupling for compressed air DIN 3238 with hogh quality and good price.We are a manufacture for claw coupling for compressed air DIN 3238,we have casting factory and machining factory.And we make claw coupling for compressed air DIN 3238 many years,so we have rich experience.
We have claw coupling for compressed air DIN 3238 for hose end 13mm(1/2"),for hose 19mm (3/4")for hose end 25mm((1").We have both with cooolar type and without collar type.And also male thread and female thread G 1/2" G 3/4" G 1".
| Hose end with collar | 12mm(1/2") |
| Hose end with collar | 19mm(3/4") |
| Hose end with collar | 25mm(1") |
| male thread | G 1/2" |
| male thread | G 3/4" |
| male thread | G 1" |
| female thread | G 1/2" |
| female thread | G 3/4" |
| female thread | G 1" |
| Hose end | 12mm(1/2") |
| Hose end | 19mm(3/4" |
| Hose end | 25mm(1") |
claw coupling for compressed air DIN 3238 is rated to 150 PSI at ambient temperature(70°F).
claw coupling for compressed air DIN 3238 are supplied with rubber washers.
claw coupling for compressed air DIN 3238 is for air and water service only.
Producttion details of claw coupling for compressed air DIN 3238.
The material of claw coupling for compressed air DIN 3238 is carbon steel,the inside with a brass gasket,the
technology is precision casting.The surface is Zn plated silver colour or yellow colour.Hose end connect with the rubber hose,male end and female with G thread connect with machines.
Hot Tags: claw coupling for compressed air similar to DIN 3238, 42 mm claw distance, with securing nut, for hose ID 19 mm (3/4"), China, Manufacturers, Suppliers, Wholesale, Buy, Factory, Low Price
